RADXA Cubie A7 Zero

RADXA Cubie A7 Zero

Allwinner™ A733 SoC powered SBC for affordable edge AI innovation

Processor

Allwinner™ A733 SoC
- Octa-Core CPU: Dual-Core Cortex - A76 @2.0GHz & Hexa-Core Cortex - A55 @1.8GHz
- NPU:  3TOPS AI accelerator for real-time edge inference

Imagination BXM-4-64 MC1 GPU
- OpenGL® ES 3.2
- Vulkan® 1.3
- OpenCL™ 3.0

RAM

LPDDR4 RAM

1GB /2GB /4GB /8GB /16GB*

Onboard high performance UFS 3.0 2-lane storage chip (optional)

- optional onboard UFS storage chip with 64GB /128GB /256GB and 512GB

Video Decoder / Encoder

• H.265MP/VP9/AVS2 multivideo decoder up to 8K@24fps
• H.264BL/MP/HP multivideo decoder up to 4K30fps
• H.264BP/MP/HP multivideo encoder up to 4K@30fps
• MJPEG encoder up to 4K@15fps, JPEG encoder up to 8K x 8K resolution
• Supports AES/DES/3DES/SM4 encryption and decryption algorithms

Interfaces

Display

1x Micro HDMI® port up to 4Kp60 with CEC and HDMI® 2.0 support

Camera

1x four lane MIPI CSI or 2x dual lane MIPI CSI Interface

Wireless

IEEE 802.11 a/b/g/n/ac/ax (WiFi 6) and Bluetooth 5.4 with BLE (external Antenna Conn)

Storage

1x Micro SD card slot

1x PCIe 3.0 single-lane FPC Connector

USB

1x USB 3.1 Type C® Port with DP Alt Mode

1x USB 2.0 Type C® Port for Power and OTG

GPIO (please choose the correct board variant)

40-pin expansion header supporting:

• UART, I2C, SPI, GPIO, PWM

• 2 x 5V DC power in/out
• 2 x 3.3V DC power out

Software

・Debian Linux® support

・Android™ 13 support (Android 13 support requires the official BSP or vendor‑provided SDK. Actual feature set may depend on further validation and licensing)

・ Hardware access/control library for Linux

Power

USB Type‑C with 5V/1A

5V power supplied through GPIO pins 2 & 4

Size

65mm x 30mm

Operation temperature:

0°C to 50°C

Certifications:

FCC, CE, RoHS

Availability:

until at least September 2034

*) please get in touch with us [email protected]
