Rock3 Model C incl. eMMC Early engineer bird Promotion

ROCK 3C features a quad core Cortex-A55 ARM processor, 32bit 3200Mb/s LPDDR4 and up to 4K@60 HDMI - including 16GB eMMC - Early engineer bird version - (while stocks last)



Rockchip RK3566 64bit quad core based SBC

With a small form-factor, various interfaces, outstanding design and performance it is the perfect entry level SBC for your personal or business oriented projects.

Rock3 Model C product details

RK3566 64bit quad core processor

Quad-core Cortex-A55, frequency 1.6Ghz

GPU

Mali G52

NPU

0.8TOPS NPU

Memory LPDDR4

LPDDR4@2112MT/s, 1/ 2/ 4/ 8GB variants

Wifi/BT Antenna

Wifi/BT with external antenna support (uFL)

Storage

eMMC module (optional)

Optional industrial level high performance eMMC module, 16G/32G/64G/128G available (click on module bottom side)

Micro SD card

uSD card slot supports up to 128GB uSD card

M.2 SSD

M.2 (M) 2230 up to 1T M.2 NVME SSD

Display HDMI

HDMI 2.0 up to 4k*2k@60

MIPI DSI 2 lanes via FPC connector

HDMI and MIPI DSI can not work at the same time

Audio

Audio 3.5mm jack with mic with improved mechanics

HD codec that supports up to 24-bit/96kHz audio

Camera

MIPI CSI 2 lanes via FPC connector, support up to 800 MP camera

Wireless

Wireless 802.11 ac

WiFi 5 / Bluetooth 5

USB

USB 3.0 HOST x1

USB 2.0 OTG port x1 (middle upper one)

USB 2.0 HOST x2

default - DEVICE, activate - HOST via serial command GPIO header

Ethernet

GbE LAN (with Power over Ethernet (PoE) support via additional PoE HAT)

IO 40-pin expansion header :

- 5 x UART
- 1 x SPI bus
- 2 x I2C bus
- 6 x PWM
- 1 x ADC
- 6 x GPIO
- 2 x 5V DC power in
- 1 x 3.3V power in

Others

RTC

RTC battery connector for time backup (optional)

Power button

Dual pin PWM fan header (controller chip onboard)

Power USB-C recommended 5V/3A (5V/5A is recommended when using with SSD)

Size 85mm x 56mm

NOTE! Fits mechanically many of the existing Raspberry Pi 4 accessories

Essentials You Need

• ROCK 3 Model C
• Power adapter with USB type C port equal or larger than (5V3A) 15W (or 5V5A - 25W with mounted SSD)
• MicroSD Card or eMMC module with eMMC-to-uSD adapter board
• Keyboard & Mouse
• Monitor with HDMI input

_________________________________________________________

Additional information & Setup instructions

https://wiki.radxa.com/Rock3/getting_started/rock-3c
